Vacuum Conveyor

Working principle
Vacuum conveyor for powder granule is mainly consisted of swirl air pump, first stage air-solid separating chamber, compressed air jetting device, second stage air-solid separating chamber, quick-open clamp, soft tube, sucking nozzle, control cabinet and three-way valve.

In the operation, the swirl air pump generates strong air flow inside the sealed conveying system. The materials will be sucked into the soft tube via the sucking nozzle with the air and flow to the three-way valve which is connected to the sealed container. Most of the material is separated by the three-way valve and drops into the container and the air stream containing some material enters into the two stages air-solid separating chambers. After two-stage filtering, the clean air is exhausted to complete material feeding process.

Technical advantages of ZKS series vacuum conveyor for powder granule

Made by SUS304 0r SUS316 to meet GMP standard;

The conveying system is completely sealed for dust-free working condition;

This vacuum conveyor can feed powder or small granule product into sealed or open containers;

The machine boy is compact, reliable and operation is very easy.

Technical parameter
